The Alpha G-1200 Electric Over Hydraulic (EOH) Brake Actuator by Deutsche Hydrapro is engineered for heavy-duty drum brake trailers requiring more power and instant response. Delivering 1,000 PSI in just 0.118 seconds and supporting up to 1,200 PSI, this actuator is ideal for over-8K axle capacity configurations. It features a sealed IP67-rated anodized housing, built-in compatibility adapter, and flexible brake line routing—all packed into a sleek, compact unit built for harsh environments.
Detailed Information:
Application
Drum Brakes (Over 8K Axles)
PSI Rating
1,200 PSI (Reaches 1,000 PSI in 0.118 sec)
Voltage
12V DC (Min. 30A feed)
Current Draw
18–24 Amps
Fluid Type
DOT 3 / DOT 4 (No DOT 4+)
Fluid Capacity
15.7 oz
Hydraulic Port
3/16" Inverted Flare
Dimensions
10" L x 6" H x 3.6"/1.7" W
Fitting:
Designed for high-capacity drum brake trailers with axle ratings above 8,000 lbs. Supports flexible 360° brake line routing and simplified mounting on utility, equipment, livestock, and cargo trailers.
Features:
Boosted Power: Rated for 1,200 PSI, perfect for over-8K drum brake systems.
Fast Reaction Time: Achieves 1,000 PSI in just 0.118 seconds for immediate braking performance.
Built-in Adapter: Internal compatibility hardware means no external modules needed.
Rugged & Weatherproof: Anodized housing with sealed tank and IP67-rated circuit board protection.
Flexible Mounting: Compact size with 360° port orientation for tight-space installations.
Interchangeable Part Numbers:
G1200-Alpha
G1200-A
G1200
Product Overview:
The EOH Brake Actuator – 1200 PSI – Alpha G-1200 by Deutsche Hydrapro is the ultimate upgrade for drum brake systems demanding higher hydraulic pressure and fast response. With smart design features, IP67-rated protection, and powerful internal electronics, this actuator provides elite braking control in a sleek and durable format—backed by a 2-year warranty and ready for whatever the road throws at you.
