The Alpha G-1000 Electric Over Hydraulic (EOH) Brake Actuator from Deutsche Hydrapro delivers industry-leading response time and rugged durability in a compact design. Built for drum brake systems on axles rated up to 8,000 lbs, this actuator reaches full 1,000 PSI braking pressure in just 0.118 seconds. Encased in a corrosion-resistant anodized housing and equipped with sealed electronics, it's engineered for tough towing environments and long-lasting performance.
Detailed Information:
Application
Drum Brakes (Up to 8K Axles)
PSI Rating
1,000 PSI (0.118 sec response)
Voltage
12V DC (Min. 30A feed)
Current Draw
18–24 Amps
Fluid Type
DOT 3 / DOT 4 (No DOT 4+)
Fluid Capacity
15.7 oz
Hydraulic Port
3/16" Inverted Flare
Dimensions
10" L x 6" H x 3.6"/1.7" W
Fitting:
Compatible with trailers using drum brake systems on 1–3 axles. Ideal for livestock, utility, equipment, and general cargo trailers operating in rugged or coastal conditions.
Features:
Rapid Response Time: Delivers full braking power in under 0.12 seconds.
Weatherproof Build: Sealed IP67-rated electronics with conformal-coated circuitry for harsh environments.
Compact Versatility: Small form factor with 360° brake line connection flexibility.
Low Maintenance: Minimal moving parts and sealed design extend product lifespan.
Interchangeable Part Numbers:
G1000-Alpha
G-1000
Product Overview:
The EOH Brake Actuator – 1000 PSI – Alpha G-1000 by Deutsche Hydrapro is engineered for trailers demanding precision, speed, and durability. With lightning-fast response, compact footprint, and rugged construction, it ensures optimal braking performance for any heavy-duty drum brake setup. Assembled in Australia and backed by a 2-year warranty, this actuator offers reliable stopping power where it matters most.
We want you to be completely satisfied with your purchase. That’s why we offer a hassle-free return policy within 30 days of delivery*. If your item is unused, in original packaging, and eligible for return, you can send it back for a refund or exchange.
*Some exclusions may apply
Some of our products are backed by a 1-year limited manufacturer warranty covering defects in materials and workmanship under normal use. If you experience any issues during this period, we’ll work with you to repair, replace, or resolve it according to warranty terms.*
*Proof of purchase required
Need it fast? We’ve got you covered. Orders confirmed before 3 PM Eastern Standard Time (Monday–Friday) are processed and shipped out the same business day. Orders placed after the cutoff will ship the next business day.
I use my trailer to haul heavy equipment and was worried about my old system. This actuator handles the load perfectly. The PSI rating is more than enough.
B
Brandon Wilson
Perfect for My Boat Trailer
I tow a boat trailer in a coastal area, so corrosion is a huge concern. This unit's anodized housing is a big plus. It's compact and tucked away nicely, and the brakes feel solid.
D
Dietrich Coundley
Rugged and Reliable
I've put this actuator through some rough conditions, and it hasn't skipped a beat. The sealed electronics are a huge benefit. No water or dust ingress.
A
Austin Pfeuffer
Better than my old one, but not perfect.
It's a huge improvement over my old system. Braking power is there, and it's much faster. I just wish the fluid reservoir was a little bigger. Still, a good product.
L
Lowe Sollime
Finally, a system that works!
I've been through a few other actuators that just couldn't handle the demands of my large livestock trailer. This one has been perfect. The braking is consistent and powerful.
