This 10K-rated left-hand hydraulic drum brake assembly is engineered for trailers using 9,000–10,000 lb axles. Built for performance and longevity, it features a 12.25" x 3.375" braking surface, 7-bolt flange, and self-adjusting functionality. This unit comes pre-assembled and is compatible with leading axle brands, making it ideal for heavy-duty trailer applications.
Detailed Information:
| Axle Capacity |
9,000 – 10,000 lbs |
| Hub Capacity |
12.25" x 3.375" |
| Bolt Pattern |
7-bolt flange |
| Wheel Compatibility |
16", 17.5" |
| Plunger Type |
Hydraulic (standard) |
| Studs |
Not applicable |
| Coating |
Protective corrosion-resistant finish |
Fitting:
Designed for left-hand (driver side) installation on 10K axles using a 7-hole flange. Compatible with Dexter, Besser Pro, and Lippert axles. Suitable for utility, livestock, car hauler, flatbed, and equipment trailers. Mounting hardware not included.
Features:
-
Self-Adjusting System: Maintains consistent shoe clearance to improve brake response and reduce manual adjustments.
-
Complete Assembly: Delivered fully assembled with bonded shoes and hardware pre-installed for fast installation.
-
Heavy-Duty Construction: Engineered from premium-grade materials for superior reliability and wear resistance.
-
Hydraulic Compatible: Works with surge actuators or electric-over-hydraulic brake systems.
-
Wide Compatibility: Matches several OEM part numbers and fits most industry-standard setups.
Interchangeable Part Numbers:
- MAT 77-1210H-1
- MAT 77-1210H-01
- DEXTER K23-410-00
- 10LHBRKAS
- AKUBRK-35
Product Overview:
The 10K Hydraulic Brake – Left Side by MT offers reliable stopping power with minimal maintenance. Built for demanding trailer applications, this self-adjusting assembly provides a secure, long-lasting upgrade that keeps your trailer operating safely and efficiently.
